100M-6Ghz Fixed Full-bands 10km Drone Detector TDOA AOA DJI Alarm Position Tracking UAV FPV Detection Security Protection System
| 起源の場所 | 広東省、中国 |
|---|---|
| ブランド名 | LDSK |
| 最小注文数量 | 1個 |
| 価格 | USD 20500 |
| 受渡し時間 | 7-10就業日 |
| 支払条件 | D/A、D/P、T/T、ウェスタンユニオン、ペイパル |
| 供給の能力 | 1か月あたり100個 |
無料サンプルとクーポンについては、ご連絡ください。
ワットスアップ:0086 18588475571
ウェチャット: 0086 18588475571
スカイプ: sales10@aixton.com
24時間オンラインでサポートします
x商品の詳細
| 型番 | TTSKXM | 製品名 | ドローン検出器 |
|---|---|---|---|
| 関数 | アラーム、位置情報、追跡ドローン | 検出頻度 | 100MHz~6GHz |
| 検知範囲 | 10km | 探知ドローンの種類 | DJI、Autel、FPV、Wi-Fi ドローンなど |
| ユースケース | 政府および公安、公共施設およびイベント、重要インフラ保護、国境警備および防衛、刑務所および司法施設、企業および高セキュリティのプライベートサイト、交通ハブ | 使用温度 | -40～+65℃ |
| 労働時間 | 24時間 | ||
| ハイライト | 10km range drone detector,full-bands UAV detection system,portable DJI drone alarm |
||
製品の説明
Please leave your WhatsApp and Email - we will contact you!
Product Features
- Full range of detection models: Capable of detecting and recognizing over 500 types of drones, including common brands such as DJI, Autel, FPV, and more
- Comprehensive frequency detection: 100MHz to 6GHz spectrum scanning with spectrum chart and waterfall chart display for abnormal signal detection
- Extended direction finding: Direction finding distance reaches over 4km in open environments
- Passive detection technology: Equipment operates without emitting electromagnetic signals, ensuring no environmental pollution
- Advanced TDOA/AOA: Single station confirms drone direction and can track ≥ 3 sorties simultaneously
Technical Specifications
| Number | Project | Parameter | Remarks |
|---|---|---|---|
| 1 | Detection frequency band | 100MHz - 6GHz | |
| 2 | Detection distance | 3 - 10km | |
| 3 | Number of detection targets | ≥20 sorties | meanwhile |
| 4 | Detection mode | 360° Passive detection | |
| 5 | Direction finding frequency band | 2GHz - 6GHz | |
| 6 | Direction finding distance | ≥3km | |
| 7 | Number of direction finding targets | Not less than 3 sorties | meanwhile |
| 8 | Directional accuracy | ~10° | |
| 9 | DF refresh rate | 10-30 times/minute | |
| 10 | Positioning accuracy | ≤20m | |
| 11 | Number of positioning trajectories | ≥5 sorties | meanwhile |
| 12 | Scan spectrum range | 100MHz - 6GHz | |
| 13 | Detecting and identifying drone models | Common brands including DJI, Autel, Fimi, Dahua, Yuneec, and most domestic models including walk-through and WiFi machines |
Applications
About Our Company
Frequently Asked Questions
Q1: Are you a factory or trading company?
We are a factory located in Shenzhen City, China. Welcome to visit us.
Q2: Why Choose Us?
- Excellent Products: Effective, Popular, Affordable
- Fast Delivery: Priority Production for Urgent/Bulk Orders
- After-Sales Service: Free Replacement for Faulty Products
Q3: What can you buy from us?
- Jamming/Detection Module
- Drone Jammer
- Drone Detector
- Integrated detection and jamming device
Q4: What is the process of placing an order?
Communication → Payment → Production → Shipment
Q5: How about the shipping time and shipping method?
Typically 5-10 business days (depending on the product). We support almost any shipping method you require.
Q6: How to contact us?
Please leave your email address/WhatsApp number, and we will contact you.
